LSH Series – Hydraulic Driven Motor Pumps

High-performance hydraulic driven pumps for fast water transfer

  • High flow capability of up to 40 L/s for fast water transfer
  • Heads up to 100 m for flexible pumping across varied sites
  • Hydraulic motor drive ideal for mobile and remote applications
  • Australian-made design proven to withstand harsh conditions
  • Available in hydraulic drive, bare shaft and motor pump options
Contact us to order

Industries Served

Based in Perth, WA, Stalker Pumps have been manufacturing pumps since 1923. As the exclusive distributor, MTP supplies the full range of Stalker Pumps, including the LSH Series hydraulic driven motor pumps.

The Stalker LSH Series is designed for high-performance water transfer, capable of emptying an average water tank within 15 minutes with flow rates up to 40 L/s and heads up to 100 m. Manufactured in Australia, the 80HL model is proven to operate reliably in tough conditions. This range is suitable for pumping clean water, sea water, raw water, process water and waste water.

Preferred by OEMs, and civil and mining contractors, the LSH Series offers long-lasting performance with full technical support and spare parts availability through MTP. Pump packages can be configured to suit a wide variety of applications, and we supply to any location across Australia. The Stalker LSH Series is also available in bare shaft and motor pump configurations.

Mining and Civil
• Dust suppression
• Site dewatering
• Water cart filling
• Remote water transfer

Industrial
• Product transfer
• Breweries and distillers
• Wineries

Municipal
• Water supply
• Swimming pools
• Effluent treatment
• Building water services

Agricultural
• Water supply
• Spray irrigation

Marine
• Dewatering (sea water)

• Max flow 40L/s
• Max head 100m
• Adjustable discharge position
• Robust construction
• Gland Packing
• Mechanical seal arrangement options
• Max Temperature with standard Mechanical seal arrangement is -10°C to 120°C

Bare shaft pump

Model Suction (mm) Discharge (mm) kW’s Absorbed Max
Operating
Speed
(rpm)
Torque (LBS) Part Number  CI/CI/PG
(With base)
80HLD 100 80 15 1800 703 5100–040112HYD
100HLD 150 100 50 1800 2345 6000–050112HYD

CI = Cast Iron

PG= Packed gland Braided graphite impregnated

Mechanical seal fitted pumps available on request
